Haze Meter - ToronHaze™
Parent Product
Product Categories
Download PDF Brochure
The Haze Meter - ToronHaze™ is designed for precise color measurement, haze measurements, and transmittance analysis of plastics, films, glass, LCD panels, touch screens, and other transparent and semi-transparent materials.
With an open measuring area, it accommodates a variety of sample sizes and shapes, allowing for flexible testing both vertically and horizontally. Utilizing incident light, this advanced meter ensures accurate and reliable results.
HAZE AND COLOR METER - ToronHaze™-720
- All-in-one measurement of color, haze, and spectral transmittance.
- Calculates total transmittance for transparent and translucent samples.
- Ideal for plastic, film, glass, LCD panels, and touch screen materials.
HAZE AND CLARITY METER - TORONHAZE™-720
- Measures clarity along with color, haze, and spectral transmittance.
- Provides total transmittance results for transparent and translucent samples.
- Suitable for plastics, films, glass, LCD panels, and touch screens.
Features of Haze Meter - ToronHaze™
- Various measurement parameters and professional clarity measurement function
- Comprehensive transmission color parameters
- Complies with ASTM and ISO standards
- Different light sources for different measurement standards
- Compensation measurement for more accurate test results
- Haze QC software included as a standard accessory
- Seven-inch Android touch screen for better user experience
- Open sample measurement area, allowing samples to be measured horizontally or vertically
- Abundant measurement fixtures
Specification of Haze Meter
Type | ToronHaze™-700 | ToronHaze™-720 |
Light Source | Haze/Transmittance: CIE-A, CIE-C, CIE-D65 Chromaticity index: A, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CMF, U30, DLF, NBF, TL83, TL84 | |
Standards | ASTM D1003/D1044, ISO13468/ISO14782 JIS K 7105, JIS K 7361, JIS K 7136, CIE No.15, ISO 7724/1, ASTM E1164, DIN 5033, Teil7, JIS Z8722, Condition C, GB/T 2410-08 standard | |
Parameters | Haze (HAZE), Transmittance (T), Spectral transmittance, CIE Lab, LCh, CIE Luv, XYZ, Yxy, Hunter Lab Munsell MI,CMYK, Whiteness WI(ASTM E313-00,ASTM E313-73, CIE,ISO2470/ R457, Hunter, Taube Berger Stensby), Yellow Index YI(ASTM D1925, ASTM E313-00, ASTM E313-73), Tint(ASTM E313-00), Heterochromatic index Milm, APHA, Pt-Co(Index of platinum cobalt), Gardner, Color difference (AE*ab, AE*CH,AE*uv,AE* cmc(2:1), AE*cmc(1:1),AE*94,AE*00) | Haze (HAZE), Transmittance (T), Spectral transmittance, Clarity CIE Lab, LCh, CIE Luv, XYZ, Yxy, Hunter Lab Munsell MI,CMYK, Whiteness WI(ASTM E313-00,ASTM E313-73, CIE,ISO2470/ R457, Hunter, Taube Berger Stensby), Yellow Index YI(ASTM D1925, ASTM E313-00, ASTM E313-73), Tint(ASTM E313-00), Heterochromatic index Milm, APHA, Pt-Co(Index of platinum cobalt), Gardner, Color difference (AE*ab, AE*CH,AE*uv,^E* cmc(2:1), AE*cmc(1:1), AE*94,AE*00) |
Spectral Response | CIE The spectrum functionY/V(λ) | |
Wavelength | 400-700nm | |
Wavelength Interval | 10nm | |
Geometry | 0/d | |
Measurement Area Sample Port | 16.5mm/21mm | 18mm/25.4mm |
Measurement Range | 0-100% | |
Haze Resolution | 0.01% | |
Haze Repeatability | Haze < 10%, Repeatability ≤0.05; Haze ≥10%, Repeatability ≤0.1%; Transmittance ≤0.1% | |
Sample Size | Thickness ≤145mm | |
Display | 7 Inches Touch Screen | |
Memory | Mass storage | |
Interface | USB-A, USB-B | |
Power | 220V (with power cable), (110V is also available) | |
Working Temperature | 5~40°C, Relative humidity 80% or below (at 35°C), no condensation | |
Storage Temperature | -20°C~45°C, Relative humidity 80% or below (at 35°C), no condensation | |
Dimension LxWxH | 598mm x 247mm x 366mm | |
Weight | 12kg | |
Standard Accessory | PC management software (Haze QC) | |
Optional | Measurement Fixture, Haze standard film | |
Sphere Diameter | 154mm | |
