Tablet Hardness Tester provides precise USP <1217>-compliant strength analysis with multiple units, auto conversion, and compact design for dependable quality control.
Tablet Hardness Tester ToronPTAB01™ M
The ToronPTAB01™ M Tablet Hardness Tester is designed for precise and consistent tablet strength analysis in laboratory and production settings. Built to meet USP <1217> standards, it delivers reliable measurement performance with high accuracy and resolution. With multiple measurement units, automatic unit conversion, and detailed calibration verification, this tester supports dependable quality control. Its compact design, front-panel labeling, and carrying strap ensure ease of use during daily operations.
Tablet Hardness Tester ToronPTAB01™ M Features
- Meets USP <1217> Pharmacopoeia requirements
- High accuracy and high resolution
- Date and time included on all reports
- Carrying strap for convenient transport
- Instrument ID and calibration label placed on the front panel for quick reference
- Three measurement units available—N, kgf, and lbf—with automatic unit conversion
- Calibration and verification provided with detailed reports
Tablet Hardness Tester ToronPTAB01™ M Technical Specifications
Model | ToronPTAB01™ M |
|---|---|
| Hardness Range | Up to 500 Newton |
| Measuring Units | N, Kgf, lbf |
| Display | OLED 1.3” |
| Test Mode | Peak, Auto |
| Platform Length | 30 mm |
| Accuracy | ± 1 N |
| Calibration | Yes with Report |
| Validation | Yes with Report |
| Tablet Size | 2 mm to 28 mm |
| Number of Samples | 50 (Per test) |
| Voltage | 5VDC - C type USB adapter |
| Dimensions (L x W x H) | 295 mm x 90 mm x 100 mm |
| Weight (Approx) | 1.650 Kg (Without Battery) |
Ordering Information
| Product | ||
| Product code | Description | Quantity |
| 0943200 | Tablet Hardness Tester ToronPTAB01-M | 1 |
| Standard Accessories | ||
| Product code | Description | Quantity |
| 0905A00023 | ToronPTAB01™ M Calibration Platform | 1 |
| 0905A00028 | ToronPTAB01™ M Knob | 1 |
| 0905A00027 | ToronPTAB01™ M Sliding Cover | 1 |
| 0908B00016 | ToronPTAB01™ M Charging Adapter with USB C Type cable, 5V/2.4A | 1 |
| 0905A00024 | ToronPTAB01™ M Waste tray Acrylic | 1 |
| 0901A00002 | Brush | 1 |
| Optional Accessories | ||
| Product code | Description | Quantity |
| 0901A00012 | S.S. Weight 5kg (Calibrated) With Certificate | 1 |
| IQOQ Document | ||
| Product code | Description | Quantity |
| 0932S15 | IQ/OQ Document For Tablet Hardness Tester ToronPTAB01™ M | 1 |
