Sprinkler Ultra-High Temperature Test Chamber — ToronFT™ SW-UHT
ToronFT™ SW-UHT Sprinkler Ultra-High Temperature Test Chamber is a high-performance thermal testing instrument specifically designed for the high-temperature resistance evaluation of fire sprinkler assemblies. Built to deliver precisely controlled temperatures up to 1000°C with excellent uniformity and stability, the ToronFT™ SW-UHT enables manufacturers and testing laboratories to qualify sprinklers for extreme thermal exposure scenarios in accordance with international fire protection standards.
The ultra-high temperature test chamber features an arbitrarily adjustable heating rate (1–40°C/min), precise temperature control accuracy of ±1°C, and outstanding temperature uniformity across its test volume — making it an indispensable instrument for high-temperature resistance qualification, heat-sensing element evaluation, and thermal durability research.
Sprinkler Ultra-High Temperature Test Chamber — ToronFT™ SW-UHT Applications
- Fire sprinkler manufacturers: high-temperature resistance qualification and heat-sensing release mechanism evaluation
- Third-party certification and listing laboratories: ultra-high temperature testing per international sprinkler standards
- R&D departments: thermal durability assessment of new sprinkler materials, bulb fluids, and fusible elements
- Fire extinguisher and suppression system component testing: high-temperature performance verification
- Academic and industrial research: materials characterization under extreme thermal loading
Sprinkler Ultra-High Temperature Test Chamber — ToronFT™ SW-UHT Key Features
- Ultra-high operating temperature: normal ambient temperature up to 1000°C — covering the full range of sprinkler high-temperature resistance tests
- Arbitrarily adjustable heating rate: 1–40°C/min — flexible ramp control to match any standard-specified heating profile
- Precise temperature control accuracy: ±1°C — ensuring repeatable, standard-compliant test conditions
- Excellent temperature uniformity: ±1% in the 100–400°C range; ±0.8% in the 500–1000°C range
- Designed specifically for sprinkler high-temperature resistance testing per international protocols
- Robust chamber construction for sustained high-temperature operation with minimal maintenance
- Intuitive control interface for straightforward temperature and time programming
Theory and Method
The standard high-temperature resistance test procedure for sprinklers involves removing the temperature-sensing release mechanism from two sprinkler assemblies and placing the specimens upright in the test chamber. The chamber is then raised to the target temperature of (800 ± 10)°C and held for 15 minutes, after which the sprinkler thread is clamped and the assembly is immediately immersed in water at (15 ± 5)°C. The specimen is then inspected to determine whether the nozzle body has been deformed or damaged.
The ToronFT™ SW-UHT achieves and maintains the required thermal conditions through high-efficiency resistance heating elements and a precision PID control system that continuously monitors chamber temperature and adjusts power delivery to maintain the set-point within ±1°C. The adjustable heating rate (1–40°C/min) allows the operator to match the ramp profiles specified by different test standards and product specifications.
Sprinkler Ultra-High Temperature Test Chamber — ToronFT™ SW-UHT Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ToronFT™ SW-UHT |
| Temperature Range | Normal ambient temperature – 1000°C |
| Heating Rate | 1–40°C/min (arbitrarily adjustable) |
| Temperature Control Accuracy | ±1°C |
| Temperature Uniformity (100–400°C) | ±1% |
| Temperature Uniformity (500–1000°C) | ±0.8% |
| Primary Application | High-temperature resistance test of fire sprinklers |
