Electric Muffle Furnace TT-MF-8-1200 is designed for high-temperature heat treatment, including sintering and heating of advanced materials such as metals, ceramics, nanomaterials, and semiconductors.
Advanced Materials Processing – Enables high-temperature sintering, annealing, and heat treatment of metals, ceramics, nanomaterials, and semiconductors. Ensures uniform heating and consistent results for advanced material development.
Metallurgical Research & Testing – Provides precise thermal treatment for alloy studies, phase transformation analysis, and oxidation resistance testing. Supports metallurgical R&D with reproducible, traceable outcomes.
Ceramics & Glass Laboratories – Ideal for firing ceramics, glaze testing, and glass transition studies. Delivers stable and uniform thermal environments to maintain material integrity and quality.
Electronics & Semiconductor Manufacturing – Facilitates controlled diffusion, thermal oxidation, and annealing processes for semiconductor wafers and electronic components. Ensures high-precision processing aligned with industry standards.
Chemical & Catalysis Applications – Suitable for catalyst preparation, pyrolysis, thermal decomposition, and chemical reaction studies. Flexible temperature programming supports complex experimental requirements.
Battery & Energy Materials Development – Supports thermal processing of lithium-ion, solid-state, and next-generation energy materials. Provides stable heating for cathodes, anodes, and electrolytes during R&D and quality validation.
Academic & Institutional Research – Widely used in universities and research institutions for experiments in chemistry, physics, materials science, and engineering. Offers safety, accuracy, and ease of use for laboratory applications.
Industrial Quality Control & Certification – Enables consistent high-temperature testing for product validation, third-party inspection, and certification. Compliant with ISO, CE, SGS, and TÜV standards for reliable quality assurance.
Furnace Shell
- Constructed from Q235 low-carbon steel with an electrostatic-resistant, corrosion-resistant finish.
- Durable metal frame helps maintain a low external surface temperature.
- Side-opening door design with right-hand hinge for convenient access.
Refractory Material
Features a multi-layer insulation system made of lightweight alumina ceramic fiber and high-performance insulation board. Asbestos-free, with low heat loss and reduced energy consumption.
Heating System
- High-quality HRE spiral resistance wire heating elements are securely embedded on the furnace surface, providing efficient, energy-saving radiant heat with a long lifespan.
- Three-sided heating (left, right, and bottom) ensures uniform temperature distribution.
- A silicon carbide base plate shields the bottom heating element, offering strong mechanical support, excellent thermal conductivity, and stable horizontal load capacity.
Temperature Control Panel
- Combines PID and SSR control for accurate temperature regulation.
- Equipped with an internationally standardized N-type nickel-chromium-silicon thermocouple, measuring temperatures from 0–1300°C with extended durability.
- Safety switch cuts power when the furnace door is opened.
Program Controller
- Advanced controller supports complex thermal processing needs.
- User-friendly interface with flexible programming options.
- Capable of storing up to 30 segments for single-curve programs.
- Built-in over-temperature and system fault alarms ensure automatic safety protection.
| Model | TT-MF-1-1000 | TT-MF-3-1200 | TT-MF-6-1200 | TT-MF-8-1200 | TT-MF-12-1200 | TT-MF-18-1200 | TT-MF-30-1200 |
| Chamber size（W xD xH）mm | 100 x100x100 | 150 x150x150 | 180x230x150 | 200x300x120 | 200 x300x200 | 250 x300x250 | 300 x500x200 |
| Outer size（W xD xH）mm | 250 x240x350 | 430x465x620 | 460x570x660 | 480 x630x630 | 480 x630x710 | 550x635x780 | 600 x870x735 |
| Max temperature | 1200℃ | ||||||
| Working temperature | 1100℃ | ||||||
| Voltage | 220V/1.2KW (110V is also available) | 220V/2.5KW (110V is also available) | 220V/3KW (110V is also available) | 220V/3KW (110V is also available) | 220V/4KW (110V is also available) | 220V/6KW (110V is also available) | 380V/7.5KW |
| Heating element | HRE Alloy resistance wire | ||||||
| Chamber material | Polycrystalline inorganic alumina ceramic fiber material prepared by wet vacuum filtration | ||||||
| Temp.Precision | ±1℃ | ||||||
| Termocouple | N Type termocouple | ||||||
| Temperature controller | Intelligent microcomputer PID temperature control instrument, SSR control, PID parameter self-tuning function; programmable 30 program segments, program temperature rise, program heat preservation, program cooling | ||||||
| Heating rate | 1-25℃/min free adjustment | ||||||
| Furnace structure | Furnace temperature control integrated structure | ||||||
| Equipment protection | Modular control, sound and light alarm signal will be sent out for over temperature and broken coupler in the working process, and the protection action will be completed automatically | ||||||
| Safety protection | The equipment is equipped with a circuit breaker, which will automatically pop open in case of short circuit leakage, which can protect the safety of equipment and operators | ||||||
| Furnace shell | High-quality cold-rolled steel plate CNC machine tool blanking processing, after welding, grinding, polishing, phosphating, pickling, surface electrostatic spraying plastic powder | ||||||
| Quality certificate | ISO9001 CE SGS TUV | ||||||
| Standard packing | 1. Furnace body 1 set 2. Temperature controller 1 set 3. Power cord 3 meters 4. Thermocouple 1 set 5. Manual 1 copy 6. Crucible pliers 1 set 7. High temperature gloves 1 pair | ||||||
| Optional | 1. Optional exhaust chimney for evacuation of volatile substances 2. Optional corundum crucible, furnace floor, shed board and other kiln furniture 3. Optional material recorder for online recording of temperature curves | ||||||
