Advanced Portable Particle Quantifier Instrument – ToronPQI™ 3000
Parent Product
ToronPQI™ 3000 – Rugged, Portable, and Intelligent - ASTM D8184
The ToronPQI™ 3000 is the flagship model of the ToronPQI-Series — an advanced ferrous debris analyzer designed for both laboratory and field use. Equipped with a 7-inch touchscreen display, USB data output, and an optional built-in rechargeable battery (ToronPQI-3000B), it delivers unmatched versatility and performance.
Using the same electromagnetic detection principle defined in ASTM D8184, the ToronPQI™ 3000 provides rapid, reliable, and repeatable PQ readings to monitor machine wear and lubricant cleanliness anywhere, anytime.
Compliance
- Fully meets ASTM D8184 requirements for Particle Quantifier Method. Each unit is calibrated and validated to ensure consistent PQ index measurement in all environments.
Applications
- Mobile maintenance and on-site oil analysis
- Industrial, marine, and aerospace condition monitoring
- Power plant and mining equipment diagnostics
- Research institutions and lubricant evaluation centers
Key Features & Benefits
- ASTM D8184 Compliance – standardized, traceable PQ measurement.
- Large 7-inch Touchscreen for intuitive operation and instant visualization.
- Rechargeable Battery Option (3000B) for true field portability.
- Rapid Measurement Cycle (7 seconds) for high throughput.
- PC Software Integration – trend plotting and data management.
- Rugged Housing suitable for harsh industrial or remote environments.
| Parameter | Specification |
|---|---|
| Measurement Range | 0 – 15 000 PQ |
| Repeatability | ± 4 PQ or ± 1 % |
| Measurement Time | ≈ 7 s |
| Display | 7″ Touchscreen LCD |
| Data Output | USB Interface |
| Voltage | AC 220 V ± 10 %, 50–60 Hz (110V is also available) |
| Battery Version (3000B) | 12 000 mAh Li-ion, DC adapter charging |
| Dimensions | 430 × 225 × 140 mm |
| Weight | ≈ 4.7 kg (3000) / 5.1 kg (3000B) |
